When the spark gap has ignited, the pulse current
causes voltage drop via the connection cables
and the spark gap, whereby the connection techno-
logy has the greatest influence.25 kV, fulfils the requirements for all insulating
flange classes according IEC 62561-3. The same
requirements are made the European recommenda-
tion Ceocor (European Committee for the study of
corrosion and protection pipes and pipeline sys-
tems). the DVGB e.
Product characteristics the spark gap ISG H
The ISG implements state-of-the-art technologies
and innovations:
• Solvent-free, environmentally friendly material
• Modern machining technology from the automotive
sector
• Chemical resistance
• Resistance oils and extreme temperature vari-
ations
• Halogen-free
• UV-stable, weatherproof
• Ignition protection type/device protection level:
Pressure-resistant encapsulation/"db" for gases,
protection through housing/"td" for dusts
• Resistant salt water
• Highest testing Class accordance with IEC
62561-3
• Tested connection technology Class according to
IEC 62561-1
• Suitable for all explosion groups and use Ex
zones 1/21 and 2/22
