Extender crossbars with flexible width Safe guiding for large hoses
● For guiding and protecting large hoses
● With mounting for noise dampers
● Cable-friendly design, high crossbar holding force
● The openable extender crossbars can fitted different ways and combinations
● Optionally openable along the inner outer radius
E4.g.150.XXXBZ50.32
R4.32
≤34
mm
≤28
mm
≤34
mm
Bi
Bi
Ba Bi
