E2/000 e-tubes 3450·3480 Further accessories
Standard separator, wide base
Separator with wide base for maximum holding force.X
3210.R.igus.0
Separator e-chain® with
extender crossbars
unassembled
assembled
Shelf,
lockable
unassembled
assembled
Steel support tray for support the lower run
● Simple one-piece support trays for the lower run
● your requirements and specification
● options available
More information From page 1356
E2/000 robust energy supply even with constant air draught and the resulting pendulum movements this 160m lift for the
Post Tower, Bonn
CFU strain relief with innovative honeycomb design
● Fast filling, openable from both sides for assembly seconds
● Flexible honeycomb design for increased holding force
● Tribologically optimised honeycomb design for the best hold
● Universal use, compact, space-saving design
More information From page 1426
.XX
120
200
220
ø80 ø80
88 188
100
85
99.200.
As standard separators are fitted every 2nd e-chain® link!
Horizontal separation
Full-width shelf locks securely into separators both ends,
giving fixed width.eu/3480
E2/000 e-tubes 3450 Further accessories
e-chains® with extender crossbar Product Range
Separator with integrated strain relief teeth
● Can integrated into the mounting bracket placed any point
● Combines strain relief and interior separation, for restricted space conditions
● Strain relief separator easy assemble without any screws
Part No.
Interior separation for e-chains® with extender crossbars
e-chains® with extender crossbars only for series 3450 large increase the interior space for the smooth guiding
of large hoses.1.4
4
