High speed communication
DriveAnalyzer and DriveOPC use the DDCS
communication protocol high-speed fibre optic
network, enabling very fast com munication betw een
the and drives. The fibre
optic network can connected the PC’s USB port
using the RUSB-02 adapter directly NDPA-02
fibre optic communications card the PC. The
collected data can displayed graphically, helping
users to:
■ Analyze motor use, load, torque and power versus
speed
■ Display inverter peak value and amplitude logger
data
■ Create inverter current versus frequency plots
■ Analyze electrical supply and network
■ Assess energy use and savings
■ Optimize individual drive and motors perform
ance
■ Generate energy savings report
