Mounting
Wall mounting -
Free-standing •
Two mounting directions:
bookshelf flat (=sideways) •
Cabling
Bottom entry exit •
Top entry exit H351 +
H353 □
Degree protection
IP21 (UL type •
IP22 (UL type B053 □
IP42 (UL type B054 □
IP54 (UL type 12) B055 □
IP54R B059 □
IP55 (UL type 12) B056 -
DTC motor control
DTC •
Software 2)
Start-up assistant 3)
Adaptive programming 3)
Optional software optimized
for different applications for
enhanced programmability:
for more details see section
“Application software and
programming” □
Control panel
Alphanumeric 4*20 character
control panel •
Control connections (I/O)
and communications
3 pcs analog inputs,
programmable, galvanically
isolated •
2 pcs analog outputs,
programmable •
7 pcs digital inputs,
programmable, galvanically
isolated can divided into
two groups •
3 pcs relay outputs,
programmable •
Thermistor relay pcs) L505 □
Pt100 relays L506 □
Possibility for external control
voltage •
Inbuilt I/O extension and
speed feedback modules:
for more details see section
“Control connections and
communications” □
Inbuilt adapters for
several fieldbuses: for
more details see section
“Control connections and
communications” □
EMC filters
EMC 1st environment
(category C2) E202 6)
EMC 2nd environment,
earthed networks only
(category C3) E200 •
EMC 2nd environment,
earthed and unearthed
networks (category C3) E210 10) 11) •
Line filter
AC choke -
LCL •
58 Summary features and options 68375126 REV 17.2009
.Summary features and options
Ordering 07LC 37
P lta Code R5-R8 nxR8i R6-R8i nxR8i R6-R8i nxR8i
kW kW
2 0
4 1.2
