2 009 Drive modules 13
. All
the drives, regardless the pow and voltage, have
the same customer interface and I/O, making system
design and training easier.
All important features and options including LCL line
filter module(s), IGBT supply module(s), inverter
module(s), common mode filters are the package. They are full
performance regenerative drives compact package.ACS800-14 single drives modules
The ACS800-14 drives are regenerative single drives
modules equipped with active supply unit.
The power range from 1700 kW.
Main standard hardware features
■ Frame sizes R7i n*R8i control board outside the
module
■ Extensive, programmable I/O
■ Three I/O and fieldbus extension slots
■ Inputs galvanically isolated
■ Optimised design for cabinet assembly
■ Modular design allowing wide variety variants
■ Compact design
■ Long lifetime cooling fan and capacitors
■ Du/dt filters standard parallel connected R8i
and single parallel connected 690 inverter
units
■ Mounting the cabinet wall frame size R7i and on
the cabinet floor for R8i
■ heels and plug connectors the R8i inverter, and
■ Coated boards
Main optional hardware features
Inverter frame size R7i:
■ Prevention unexpected start-up
■ fuses, fuse bases DC-fuse switch
■ Assembly plates for R7i units
■ du/dt filters
■ com ode filter for motor protection -on-off
control for cooling fan with internal charging option
Inverter frame sizes R8i n*R8i:
■ Prevention unexpected start-up
■ fuses, fuse bases DC-fuse switch charging
circuitry -du/dt filters options 400 500 V
■ Mechanical accessories Rittal TS8 cabinets
■ IP21 IP54 cabinet door roof mechanical kits
■ Accessories kits
■ Common mode filters for motor protection
3A FE68404592 REV .7
