Drive monitoring
A set drive parameters and/or actual signals, such
as torque, speed, position, current etc. This achieved with dedicated
gateway concept betw een the fieldbus systems and
ABB drives.
Commissioning and assembly
The modular achine configuration allows pre
commissioning single achine sections and
provides easy and fast assembly the com plete
installation.
Manufacturing flexibility
Drive diagnostics
Accurate and reliable diagnostic information can be
obtained via the alarm, limit and fault words, reducing
the drive downtime and therefore also the downtime
of the manufacturing process.
Drive parameter handling
Total integration the drives the production
process achieved single parameter read/write up
to com plete parameter set-up download.
The fieldbus gateway odule can easily mounted
inside the drive.2009 Control connections and communications 33
. Because the wide range fieldbus
gateways, your choice automation system is
independent your decision use first-class ABB
AC drives.
Reduced installation and engineering effort
Drive control
The drive control word (16 bit) provides wide
variety functions from start, stop and reset ramp
generator control.Options
Fieldbus control
ABB industrial drives have connectivity ajor
automation systems.
Design
The use fieldbus control reduces engineering time
at installation due the modular structure the
hardware and software. Typical setpoint values such as
speed, torque and position can transmitted the
drive with bit accuracy.
Cabling
Substituting the large amount conventional drive
control cabling with single twisted pair reduces costs
and increases system reliability.2.
Currently available gateways
Fieldbus Protocol Device profile Baud rate
PROFIBUS DP, DPV1 PROFIdrive 9.6 kbit/s Mbit/s
(+K454) ABB Drives *)
DeviceNet AC/DC drive 125 kbit/s 500 kbit/s
(+K451) ABB Drives *)
CANopen Drives and motion control kbit/s Mbit/s
(+K457) ABB Drives *)
ControlNet AC/DC drive Mbit/s
(+K462) ABB Drives *)
Modbus RTU ABB Drives 600 bit/s 19
