Mounting
Cabinet mounting ■
Separate drive control unit (RDCU) •
Cabling
Supply bottom entry (module terminals) •
Supply top entry (module terminals) •
Bottom exit (module terminals) •
Side exit (module terminals)
Top exit the module •
Enclosure class
IP00 (UL open chassis) •
DTC motor control
DTC •
Software
Start-up assistant •
Adaptive programming □
Optional software optimized for different
applications for enhanced programmability: for
more details see section “Application software
and programming” □
Control panel
Alphanumeric 4*20 character control panel □
Control panel mounting platform □
Control connections (I/O) and communications
3 pcs analog inputs, programmable, galvanically
isolated 3)
2 pcs analog outputs, programmable 3)
7 pcs digital inputs, programmable, galvanically
isolated can divided into two groups 3)
3 pcs relay outputs, programmable 3)
Possibility for external control voltage •
Inbuilt I/O extension and speed feedback
modules: for more details see section “Control
connections and communications” □
Inbuilt adapters for several fieldbuses: for more
details see section “Control connections and
communications” □
Line filter
AC choke •
LCL •
Output filters
Common mode filter 3)
du/dt filters 7)
Braking
Brake chopper ■
Brake resistor
Regenerative braking •
Rectifier bridge
6-pulse that can connected 12-pulse
one also 8)
Safety option
Prevention unexpected start-up □
Approvals
CE •
UL, cUL, CSA •
GOST •
Auxiliary option kits
Fuses fuse bases ■
DC-fuse switch ■
Contactor breaker ■
Assembly kits for Rittal TS8 cabinets ■
• Standard
□ Option inbuilt
■ External accessory, plus code
- Not available
1) Frame sizes R2i-R5i inside the module.2009
.5-2240 kW
690 5.7.
60 Summary offeatures and options 3AFE68404592 .
6) For frame size R2i-R5i only.Summary features and options
Ordering
Code
