Three recording channels are available.
Each channel can assigned the following measurands:
Measured
value
Description Reference value for resolution
--- recording ---
Une Zero sequence voltage (50 compo-
nent)
momentary Une
Une_Phi Angle between Une and Usync 360°
I1 Current from channel I_nominal
I1_Phi Angle between and Usync 360°
I2 Current from channel I_nominal
2_phi Angle between and Usync 360°
Ipos Coil position Imax (coil end value A)
The memory designed save new value only when value changes, meaning that the
values for the resolution relate changes the measured value %.6 Menu item Recorder (recording measured values)
Figure 111: Menu item Recorder (default allocation the three recorder channels)
Important values that document the quality the regulation are stored the REG-DP/
REG-DPA and can displayed graphic recorder mode.
11. The
third channel cannot displayed but saved.
The recorder data can downloaded the Logbook tab WinEDC.
The first two channels can displayed the regulator's screen timeline diagrams
