0 Linearity error
The movement the potentiometer wiper recorded during the calibration the coil.
0 End switch Lower
The value the potentiometer the lower end switch position expressed %.
0 Coil backlash
Coil backlash result the mechanical hysteresis the drive system between the up-
ward and downward movement.
0 Coil runtime
Indicates the time the coil needs move from the lower the upper end switch.2.
Normally, the change position should produce linear function across the coil's runtime.Page 156 Detailed description REG-DP/ REG-DPA parameters
We take care it.
11.4.2.
0 End switch Higher
The value the potentiometer the upper end switch position expressed %. The
values are read-only.
If the non-linearity bigger than 2%, the potentiometer's wires should checked.
0 Coil overrun
The coil overrun expressed indicates how many Ampere the coil continues to
run after the stop command.3 Linearization table
Figure 102: Menu Linearization table
.
This menu displays the results the calibration process described Chapter 10
