The maximum number electronic ballasts transformers which may
be connected the control unit for 1–10V control input calculated
from the sum the control currents.
Installation instructions
Test electronic ballast for suitability before installation! Some electronic
ballasts briefly switch the fluorescent lamps the maximum brightness
when the supply voltage applied. Only after this time does such an
electronic ballast react the applied control voltage and set the bright-
ness accordingly. Operation via mechanical button (NO con-
tact).
Use only electronic ballasts and fluorescent lamps transformers from
a single manufacturer and single type and power level.
Use only electronic ballasts with standardised interface pursuant to
DIN 60928 (electrical isolation between mains supply and 1–10V
input). ambient temperature: +50°C
Dimensions H): 175 18mm
AC 230 ~
Control unit 1–10V connection
Control unit 1–10V for switching and dimming fluorescent lamps via
electronic ballast with 1–10V control input electronic transformers
with 1–10V control input. With this, the total current of
200mA may not exceeded (see technical data from the transformer
and electronic ballast manufacturer).649
Gira electrical installation systems
Control unit 1–10V
I
Technical
information
Control unit 1–10V
Order No. 0360 00
Technical data
Rated voltage UN
: 230V~, 50Hz
Connected load:
- Ohmic load
- Electronic ballast, transformers
2300W
type-dependent
Control voltage: 1–10V
Control current: max.
AC 230 ~
Control unit 1–10V connection phases
. 200mA
Switching contact: Relay
Short-circuit protection:
(via circuit breaker)
10A
Electrical isolation 1–10V: 2kV basic insulation
Max
