. short-circuit protection
(1181 00)
2-way wiring: via mechanical 2-way switches;
2-way wiring with dimmers is
not possible
N
L
AC 230 V~
N
L
(A)
Connection light bulb dimmer
N
L
AC 230 V~
0106 00
N
L
(A)
2-way wiring
Explanation (A)
0301 Light bulb dimmer with pressure/2-way switch
and inscription space (WP SM)
0302 00, 1181 Light bulb dimming insert with pressure/2-way
switch
System 2000
Zero-voltage relay insert
Order No.
1 Further auxiliary units.5 250V
(0301 30, 0302 00)
electron. 100m
Circuit breaker: Carry out pursuant local direc-
tives, but more than 10A
Switching contact: Zero-voltage relay contact, suitable
for switching second external
conductor, SELV
AC 230 V~
1148 00
Connection System 2000 zero-voltage relay insert
AC 230 V~
. button
-
System 2000 auxiliary unit for
presence detector and automatic
control switch 0335 00
Unlimited
10
Total length
Auxiliary unit cable: max. 1
1148 0333 0335 0151 00
Connection various auxiliary unit inserts System 2000 zero-voltage relay
insert.645
Gira electrical installation systems
Light-bulb dimmer relay insert Flush-mounted inserts
I
Technical
information
Light bulb dimming insert with
pressure/2-way switch
Order No. 0301 30
Order No. 1181 00
Technical data
Rated voltage UN
: 230V~, 50Hz
Ambient temperature: +5°C +45°C
Connected load 25°C:
- 230V light bulbs
- halogen
-
Mixed loads specified load
types
60 450W (0301 30)
60 600W (0302 00)
100 1000W (1181 00)
60 450W (0301 30)
60 600W (0302 00)
100 1000W (1181 00)
60 450W (0301 30)
60 600W (0302 00)
100 1000W (1181 00)
Fuse protection: 2. 1148 00
Technical data
Rated voltage UN
: 230V~, 50/60Hz
Ambient temperature: +5°C +35°C
Connected load:
- Light bulbs
- halogen
-
Mixed loads specified load
types
800W
750W
permitted
Minimum load: 12V, 100mA
Number auxiliary units:
-
System 2000 auxiliary unit
0333 00, mech
