Dimming KNX
Specifications Order No.
-
- Delay for actively transmitted feedback messages following bus
voltage recovery. 100 W
-
- Compact fluorescent lamp: typ.
-
- Installation DIN top-hat rail.
-
- Dimmable brightness range can set. W
Switching current for motors: 2.
-
- Elapsed operating time meter for recording switch-on time.
-
- VDE approval accordance with 60669-1, 60669-2-1.
-
- Central switching function for control all dimming channels.
-
- Linking function and eight scenes per dimming channel
possible.
-
- Automatic manual selection dimming principle according to
load. unit Specifications Order No.
-
- Feedback for "switching" and "brightness value".
More information
Technical information 635
Dimming
KNX dimming actuator, 1-gang
. mm²
Dimensions
-
- Modular widths (MW): 4
Notes
-
- Power extension using Gira power boosters.
-
- Block function forced setting function can parameterised
for each output.
-
- Alarm telegrams for short circuit, overload, and load failure.
-
- Staircase light function with advance warning function via
time-controlled reduction lighting activation permanent
lighting.
-
- Idle-state, short-circuit, and excess temperature-proof
-
- Manual actuation the outputs independent the bus (building
site operation also possible).3 A
Number universal power boosters
-
- Trailing edge: max. unit PS
Price system (PS) 14: reduced discount Gira electrical installation systems
KNX
system
devices,
actuators,
sensors
20 –500 W/VA
DRA plus 217100 2171 1/100 26
COptional accessories
System 3000 universal LED power booster DRA D256
Tronic transformers
Features
-
- Dim actuator with integrated bus coupler.
-
- Reactions after bus voltage failure and recovery can set.
Technical data
KNX medium: TP1-256
Rated voltage: 110 230 50/60 Hz
Connected load (AC 230 V)
-
- Light bulbs: 500 W
-
- halogen lamps: 500 W
-
- Wound transformer: 500 VA
-
- Gira Tronic transformer: 500 W
-
- Wound transformer with
NV-LED:
20 100 VA
-
- electronic transformer with
NV-LED:
typically 100 W
-
- LED lamps: typ.
-
- For building site operation, outputs can operated manually
without bus voltage with operating voltage only.
Scope supply
-
- KNX connection and junction terminal included the scope of
supply.
-
- Switch-on behaviour for relative dimming command can be
parameterised. 500 W
-
- Leading edge: max.
Functions
-
- Independent control the dimming channels.
-
- Time functions (switch-on/off delay, staircase light function).
-
- The dimming actuator, 1-gang can also used speed
regulator for speed control single-phase electric motors.
-
- Bulb-saving switch-on and switch-off
-
- Automatic setting and scaling the dimmable brightness range
when using universal power boosters.
-
- The performance dimming channel the "OFF" state during
reception relative dimming command can parameterised
(switching and dimming response).
-
- Dimming behaviour and dimming characteristics can be
parameterised.
-
- Feedback connected load type. 100 W
Connected load (AC 110 V)
-
- Light bulbs: 250 W
-
- halogen lamps: 250 W
-
- Wound transformer: 250 VA
-
- Gira Tronic transformer: 250 W
-
- Wound transformer with
NV-LED:
20 VA
-
- electronic transformer with
NV-LED:
typically W
-
- LED lamps: typ.
-
- Switching and dimming light bulbs, halogen lamps,
dimmable HV-LED lamps, dimmable compact fluorescent lamps,
dimmable inductive transformers with halogen NV-LED
lamps, dimmable electronic transformers with halogen or
NV-LED lamps. W
-
- Compact fluorescent lamp: typ.
-
- Building site operation: Outputs can operated manually
without bus voltage with operating voltage only. 420 VA
Connections
-
- KNX: Connection and junction terminal
-
- Load: Screw terminals
-
- max.
-
- Load type and dimming method can configured: Universal
(with automatic calibration procedure), electronic transformer/LV
LED (capacitive/phase cut), conventional transformer/LV LED
(inductive/phase cut), LED (phase cut) LED (phase cut)
