DUAL SYSTEM for crimping flexible conductors KRF/KSF
terminals for demanding applications 10-400 mm²
Properties:
• patented crimping
• for crimping flexible conductors according IEC 60228, type class 5
• used with Elpress KRF/KSF terminals
• for extra harsh environments such cars and trains, where the terminals in
addition electrical properties are also exposed to, for example, corrosion,
mechanical durability and vibration
• meets IEC/EN 61238:1
• meets corrosion requirements according DIN 046-37
• meets the requirements for vibration according 155
• meets the requirements mechanical strength according SEN 10
Crimping sequence
Contact crimping takes place two-stage movement, first hexagonal
crimping that provides optimal symmetrical contact with the conductor, which
means that wires are broken come apart the edge facing the connector.
Properties:
• ergonomic design ensures optimum balance the user’s hand
• crimp monitoring with warning light and signal when the correct pressure/full crimp not achieved
• LED work lighting
• possibility documentation each crimp for unique service control
• crimp force 124 (13 tonnes)
• crimps/charging: 60-120 depending size and temperature
• crimp time: 4-12s depending size
• usage temperature -20°C +40°C
• Li-Ion Makita, 5. and without
Battery/Charger
10-300 16-400 16-240 PVX1300-US Punch, Dual, Hexagonal, Oval 6,7 412 319 Delivered with battery and US-charger
10-300 16-400 16-240 PVX1300DB-US Punch, Dual, Hexagonal, Oval 7,3 412 319 Delivered with batteries and US-charger
10-400 16-400 16-240 PVX1300-WOBC Punch, Dual, Hexagonal, Oval 4,8 412 319 Delivered without Battery/Charger
.0 Ah, 18V
• charger Li-Ion Makita, charging time min 110-240VAC 50-60Hz
• DUAL: 300 mm²
Crimp geometries
mm²
(Cu)
mm²
(Stranded
Al)
mm²
(Solid
Al)
Name Crimp geometry
Net
weight
(kg)
Length
mm
Width Height Note
10-400 16-400 16-240 PVX1300 Punch, Dual, Hexagonal, Oval 6,7 412 319 Delivered standard case
10-400 16-400 16-240 PVX1300DB Punch, Dual, Hexagonal, Oval 7,3 412 319 Delivered with batteries
10-400 16-400 16-240 PVX1300-ADV Punch, Dual, Hexagonal, Oval 14,2 412 319 Delivered CASE ADV.
This followed indent crimping, which provides 30% better electrical pro-
perties.
10-400 16-400 16-240 PVX1300-WOBC-
ADV
Punch, Dual, Hexagonal, Oval 12,4 412 319 Delivered CASE ADV.
PVX1300/PVX1300DB
Tested and certified battery-powered crimp gun for contact crimping Cu-terminals, type KR/KRT 10
mm², KS/KST mm², KRF/KRD/KRT 16-400 mm², KSF/KSD/KST 16-400 mm², Al-terminals 16-400 mm²
(-240 solid), DIN 46235 10-300 mm², sleeves 240 mm² total area (C95-120).
10-400 16-400 16-240 PVX1300DB-ADV Punch, Dual, Hexagonal, Oval 14,2 412 319 Delivered with batteries and CASE ADV
