General information about uninsulated terminals
System Elpress
System Elpress consists terminals and
tools that are designed and tested to-
gether give certified crimping result.
Designation example
Cat B1532R (G, HO, FLS etc)
B uninsulated
15 Area (1.
• Use the recommended torque according
to the screw manufacturer’s instruc-
tions.
Examples crimps using Elpress uninsulated
terminals.2 mm)
G fork terminals
GS fork terminal
H tabs (male)
HN tab with locking lip
HA bullet
HO socket
R ring terminals
SR pin terminal
FLS receptacle, rolled type
FLSB receptacle rolled type
FLSH receptacle male rolled type
FLSN receptacle locking lip rolled model
FLSV receptacle angled rolled model
Screw and washer
The following apply for bright galvanized
type nuts and screws, with strength class
8.
• Always use hard flat washer reduce
friction against the connection surface
and the edge pressure, hardness min
HB200. technical report, IEC 61238-2,
sets out the following recommendations
regarding screw sizes for connecting ter-
minals with and plate provided that
mounting takes place with washer and
with the correct tightening torque.
Uninsulated terminals
Elpress through connectors, ring, pipe,
fork and pin terminals are made of
high-quality copper 99.
IEC recommendations
IEC The International Electrical Com-
mission publishes internationally viable
standards which, although not directly
binding, often have great impact and are
used the basis for international de-
liveries.
Marking uninsulated terminals
Elpress uninsulated terminals are marked
with logotype, area and any screw diame-
ter facilitate work and checkability.
This ensures that users will feel confident
when using our systems, and that se-
cure connection will achieved through
the proper handling our products. Make
sure calibrated regular intervals
according the supplier’s instructions.
UL certified products are delivered with
UL marking the label including the
UL file number and/or certification code for
control inspector
