The cable lugs are placed between the washer
on the clamp support and the lock washer the bolt the
WF terminal.
The connectors are attached the threaded pins using
crimped cable lugs and each connection secured by
tightening the hexagon nut.
Connections range from mm² 300 mm².
All stud terminals are tested international standards
(EN 60947-7-1, 50124-1, DIN 61373, 50343,
DIN 45545-2, NFF 61-017) and satisfy the
requirements contained therein. Tightening the hexagon
nut causes the cable lugs’ flaps press against one another
– thereby creating secure contact. Stud terminals with threaded
pins from M16 can used according the wire
cross-section.
WF WFF series
• For voltage ranges 1000 V
• For use with special epoxy resin partition plates even up
to 2,300 and 520 A
WF single-stud terminals
• Four connectors can securely connected without a
problem
• Three connectors even without compromising the rated
data
WFF two-bolt terminals
• Two connectors can reliably connected
Accessories
We offer extensive range accessories for our stud
terminals. detailed description available the
accessory overview pages. With the WFF stud terminals, the cable lugs
contact directly the current bar.
Handling
Cable lugs are crimped onto the cable lugs connect the
connectors.396 3029140000
A
Universal
range
.Screw connection with stud technology
Overview
Power transmission
The comprehensive range stud terminals ensures secure
connections for all power transmission applications.
Stud terminals
product overview
size thread M10 M12 M16
single-stud terminals •
twin-stud terminals •
twin-stud terminals WFF •
twin-stud terminals 4000 (up 4000 •
A
