5 mm² 300 mm²
A.
• Tightening the hexagon nut causes the cable
lug flaps press against one another –
thereby creating secure contact
Clamped copper conductors:
• solid
• stranded
• finely stranded
• finely stranded with ferrule with plastic collar
• finely stranded with ferrule
without plastic collar
• finely stranded twin ferrule with plastic collar
Clamped copper conductors:
• According DIN 234
• According DIN 235
Connection sizes:
0. The fact that is
simple handle makes
clamping yoke technology the universal
screwed connection solution for all
conductor types.Connection technologies
Screw connection with clamping
yoke technology
Screw connection with stud
technology
The patented Weidmüller
clamping yoke system sets
standards.
With stud technology, you
are relying affordable
and, the same time, safe
and robust connection
solution for applications particularly
harsh conditions.3
3029140000
A
Universal
range
.
Connection principle:
• The clamping yoke system combines the
specific properties steel and copper.
While the clamping yoke and clamping screw
are made hardened steel, the current is
made copper high-quality copper alloy
• The clamping yoke pulls the conductor to
be connected against the current bar
• Our clamping yoke system maintenance-free
and guarantees vibration-resistant connections
Connection principle:
• Cable lugs crimped onto the ends the
conductor ensure secure connection
• The cable lugs are put between the washer
on the clamp support and the thrust washer
on the stud.13 mm² 300 mm²
Connection sizes:
1. The reverse sides the cable
lugs are positioned against one other
