Heating Actuator Electrical Heater Panels CHAZ-01/01
Technical Specifications
Power supply 230-400VAC, 50Hz
Anschlüsse Steckkontakte
Power consumption: 0.
Note: order ensure optimal measurement the room temperature, recommend the use “heating actuator for E
panels“ combination with room controller. -25 +70°C
Colour the enclosure similar RAL9001
Dimensions the enclosure HxWxD 108 mm
Approval Printed onto the device
General information:
Operating mode red LED Heating green LED ECO
COMFORT: ON, only when heating requested OFF
ECO: Night, frost, holiday, standby, window open ON, only when heating requested ON, comfort extension possible
OFF: OFF Flashing (1x every 10s)
BACKUP*: ON, only when heating requested OFF
* also possible without heating actuator, "Emergency mode" with handwheel the heating actuator and internal sensor the
electrical panel.
Attention:The heating actuator for electrical panels expects cyclical telegram least once every hour. this case, please follow the mounting instructios the room controller.7W/230VAC, 1W/400VAC
Pre-protection Power circuit breaker 16A, charateristic C
Frequency 868,300MHz
Type transmission Bi-directional, via coded telegrams
Indoor range Typically 50m, walls ceiling
(depending wall thickness and material !!)
Compatible with the following heater panel types:
Dimplex Unique and DimplexTopaz, Dimplex
Classic, Siemens Unique, Siemens Classic,
in some cases Clima Extend
Degree protection IP20
Degree soiling 2
Operating temperature +45°C
Storage/transportation temp.
By pushing the “Comfort extension” button again you will get back “ECO” (green LED ECO ON).
When the “ECO” operating mode active (green LED ECO ON), possible control the pre-set temperature the “hand-
wheel” (green ECO-LED switches OFF) pushing the “Comfort extension" button (base setting hours).
.
Whenever the heating requested, both “COMFORT” and “ECO” mode, the red LED “HEATING” will on.
Otherwise the device will automatically switch "BACKUP" mode emergency mode)
