. "Heating actuator for electrical panel" with assigned “Push-button” (binary input M2, remote control,…) allowing to
change the operating mode
Application: When you are absent, the temperature will reduced, when you are the house, the
temperature will increased again
"Present ON"
Set-point temperature: Handwheel the electrical panel
Real temperature: Integrated temperature sensor the electrical panel
LED Heating (red): when heating requested
LED ECO (green): OFF
"Present OFF"
Set-point temperature: Depending the setting "Operating mode set-point value" (pre-setting 18°C)
Real temperature: Integrated temperature sensor the electrical panel
LED Heating (red): when heating requested
LED ECO (green): ON,
Comfort extension can now activat-
ed (pre-setting hours)
When comfort extension active, the
set-point temperature the hand-
wheel the electrical panel will be
applied.
3. Other combinations are course possible, too. "Heating actuator with electrical panel” only, without any assigned sensors
Application: Backup mode Emergency mode
Real temperature: Internal sensor the electrical panel
Set-point temperature: Handwheel electrical panel
Comfort: -
Eco: -
Off: -
2.EATON SYSTEM
71
Configuration possibilities
The configurations specified here are just few examples.
1. "Heating actuator for electrical panel" with assigned "Room controller for electrical panels", just for specifying the set-
point value
Application: Central set-point specification for several rooms equipped with electrical panels, the real
values can used from each the internal sensors the electrical panels
"Reduction switch RC" DAY
Set-point temperature: Handwheel (+-3°C) and reduction switch (21°C) the "Room controller for electrical panels"
Real temperature: Temperature sensor integrated the electrical panel
LED Heating (red): when heating requested
LED ECO (green): OFF
"Reduction switch RC" Night
Set-point temperature: Handwheel (+-3°C) and reduction switch (8°C) the "Room controller for electrical panels"
Real temperature: Temperature sensor integrated the electrical panel
LED Heating (red): when heating requested
LED ECO (green): ON,
Comfort extension can now activated (pre-setting hours)
When comfort extension active,
the set-point temperature the
handwheel the electrical panel
will applied
