Overhead line connectors and mm² for FeAl-line
Properties:
• outer Al-sleeve inner steel sleeve for the centre strands
• meets the requirements 4241241
mm²
(Cu)
Name
d
mm
d1 Tool
Number of
crimps
Marking
Pcs/
pack
62 LFEAL62 14,3 16,0 310 V1300, V250, V600 LFEAL XXXX 3
99 LFEAL99 13,5 18,7 360 V1300, V250, V600 LFEAL 20
XXXX, LFEAL 8
XXXX
3
Elpress logotype included the marking. Marking XXXX Year, week.3
07
Overhead line connectors 241 mm²
for AlMgSi (Super and Al59
Properties:
• material aluminium
• for splicing overhead lines
• meets the requirements 4241241
• the connector tube supplied with contact paste the inside
• the conductor must cleaned
mm²
(Cu)
Name
d
mm
D Tool
Number
of crimps
Marking
Pcs/
pack
31 LFS31 200 V600, V1300, V250 LFS31 ALMGSI XXXX AL-59 10
62 LFS62 200 V600, V1300, V250 LFS62 ALMGSI XXXX AL-59 10
99 LFS99 13,5 18,7 250 V600, V1300, V250 LFS99 ALMGSI XXXX AL-59 10
157 LFS157 17,5 400 V1300, V250 LFS157 ALMGSI XXXX AL-59 5
241 LFS241 450 V1300, V250 LFS241 ALMGSI XXXX AL-59 5
Crimp sequence, see picture.
.
2x10 crimps are required when crimping LFS99 with T2600, V600, V611 and PVX611.
Crimp sequence, see picture
