During camera startup, the LED behavior corresponds the POWERLINK mode described the follow-
ing section.
Extended LED status indicator functionality: Firmware version 111 and later
If one the bits parameter CameraStatus set, which affects parameter ImageAcquisitionReady, the
camera blinks with green double flash (like status PRE_OPERATIONAL_2 the POWERLINK mode). For additional information, see the section the corresponding mapp Technol-
ogy Package Automation Help.2 LED status indicators
The LED status indicator the multi-color LED strip integrated into the housing frame the front cover.
After startup completed, the LED status indicators can configured Automation Studio using mapp
Vision.
Information:
The parameters and registers mentioned this section are part the mapp Technology
Package.
If none the above cases applies, the LED status indicator lights green.
20 Smart Camera Smart Sensor User's manual 1.Operating and connection elements
C-mount
6.
If none the bits that affect ImageAcquisitionReady are set and ImageAcquisitionReady FALSE the
bit "MAPPVISION_HMI_ACTIVE" set CameraStatus, the LED status indicator switched blue
