Check that the circuit board and fan voltages correspond with the manufacturing
specification and the rated marking plate.
• Voltage test control circuit, 1,0 during 1s.
• Test stamp green area label right hand side the softstarter.
Do not apply test voltage before the test object connected.
Between connection block 1,2,12,13,14,15,16,17,18,19,20 and earth.
• Visual check the completed product.
• Function test the keypad and display.
• Test by-pass function, and that indication the unit correct.
Tripping current mA.
The test voltage may not connected until the test object connected. Also check that indication correct the
unit.
Delivery
• Each completed and tested softstarter delivered with installation maintenance manual.
Test between the phases: 1,4 during 1s. The number
combination the stamp stands for ”year” and ’’calendar week” production and
testing.
Test between the phase and earth: 2,7 during 1s.
• Voltage test main circuit:
Tripping current mA.
• Programming.
• Function test start ramp and stop ramp.
J I
M IP
