This how works:
• The cable conductor spliced with a
shearbolt connector fitted with torque
screws that shear when the correct
torque reached. Insu-
lation done with suitable heat shrink
insulation.
• Sector-shaped conductors not need
to rounded.
The kit consists shearbolt connectors
with partition and heat shrink insulation.
Cable type round
mm²
Cable type sector
mm²
Name Note
10-50 16-50 KSC50N-1-4HS outer jacket, SC50N, inner tubes and abrasive cloth.
95-240 95-240 KSC240N-1-4HS outer jacket, SC240N, inner tubes and abrasive cloth.
• With the attached filler piece you can
easily splice 3+1 cable cable.
Shearbolt connectors with heat shrink insulation, 1kV
Kit for splicing 3-, and 5-conductor cable according IEC 60228.2
Heat shrink connectors Shearbolt connectors with heat shrink
insulation, 1kV
Complete kits click heat
Complete kits for easy splicing kV
plastic insulated 3-, and 5-conductors.
.
70-150 70-150 KSC150N-1-4HS outer jacket, SC150N, inner tubes and abrasive cloth.
35-95 50-95 KSC95N-1-4HS outer jacket, SC95N, inner tubes and abrasive cloth.
For both Cu/Al solid and stranded conductors.
Conductors are spliced using shearbolt
connectors Tighten the screw using a
socket wrench, until shears the cut-off
groove.
10-50 16-50 KSC50N-1-5HS outer jacket, SC50N, inner tubes and abrasive cloth.
Shrinkage the insulation achieved by
using heat.
• The insulation internally coated with
adhesive that melts when heated
• When the adhesive pressed forward
out the shrunken body, the installa-
tion finished and the joint becomes
entirely watertight.
The connection between the cable and
the through connector done means
of screws shearbolt terminal.
35-95 50-95 KSC95N-1-5HS outer jacket, SC95N, inner tubes and abrasive cloth.
70-150 70-150 KSC150N-1-5HS outer jacket, SC150N, inner tubes and abrasive cloth.
95-240 95-240 KSC240N-1-5HS outer jacket, SC240N, inner tubes and abrasive cloth.
Kit for 5-conductor cable.
• The different phase conductors are
insulated with heat shrink insulation of
polyolefin
