Control
cables
LF
Označenie káblov str. Values are notguaranteed.
Nominal thickness ofthe sheath, informative diameters and weightofcables.km] min. 50”
Kapacitná nerovnováha [pF/500m] Capacitance unbalance [pF/500m] max.
k
D C
t
[mm]
d
[mm]
m
[kg/km]
t
[mm]
d
[mm]
m
[kg/km]
1x2x0,8 2,0 8,0 2,0 9,0 68
2x2x0,8 2,0 10,5 140 2,0 11,5 97
3x2x0,8 2,0 11,5 154 2,0 12,5 142
4x2x0,8 2,0 12,0 138 2,0 13,0 156
6x2x0,8 2,0 12,5 172 2,0 13,5 190
7x2x0,8 2,0 13,0 188 2,0 14,0 206
12x2x0,8 2,0 16,5 292 2,0 16,5 310
16x2x0,8 2,0 18,5 360 2,0 18,5 378
24x2x0,8 2,0 23,5 514 2,0 23,5 532
30x2x0,8 2,0 24,0 592 2,0 24,0 610
1x2x1,0 2,0 9,2 2,0 9,7 104
2x2x1,0 2,0 13,2 142 2,0 13,7 158
3x2x1,0 2,0 13,3 186 2,0 13,8 204
4x2x1,0 2,0 14,3 218 2,0 14,8 239
6x2x1,0 2,0 16,2 283 2,0 16,2 284
7x2x1,0 2,0 17,4 302 2,0 17,3 317
12x2x1,0 2,0 20,0 458 2,0 20,0 475
16x2x1,0 2,0 22,5 569 2,0 22,5 576
24x2x1,0 2,0 27,4 764 2,0 26,8 777
k konštrukcia (construction)
t nominálna hrúbka plášťa (nominal thickness ofthe sheath)
d informatívny priemer kábla nad plášťom (informative diameterofthe cable over the sheath)
m informatívna hmotnosť kábla (informative weightofthe cable)
PRENOSOVÉ PARAMETRE TRANSMISSION PARAMETERS
POZNÁMKA Pri konštrukcii 1x2 môže byť prevádzková kapacita páru vyššia 10%. prípade otázok kontaktujte technickú podporu.km] Insulation resistance [GO. 144-145/Cable labeling -page 144 145
Farebné značenie prvkov Colorcode ofcomponents
počítací pár
(counter pair)
smerový pár
(refer pair)
nepárny pár
(odd pair)
párny pár
(even pair)
a žila
(a core)
b žila
(b core)
a žila
(a core)
b žila
(b core)
a žila
(a core)
b žila
(b core)
a žila
(a core)
b žila
(b core)
červená oranžová sivá biela čierna hnedá žltá biela
(red) (orange) (gray) (white) (black) (brown) (yellow) (white)
Nominálne hrúbky plášťa, informatívne priemery hmotnosti káblov. Ifnecessary, contact technicalsupport. odpor elektrickej slučky [D/km] Max. 10
